產(chǎn)品中心
| 型號 | 焦距 | 倍率 | 最大像面尺寸 | 通光孔徑 | 畸變 | 工作距離 | 接口 | 濾鏡螺紋 | 分辨率 |
| XM2003C | 20 | 0.0358X | φ30 | 4.5 | ﹤0.2% | 557.4 | V | M43×P0.75 | 4K7μ |
| XM2801A | 29 | 0.1X | φ30 | 4 | ﹤0.1% | 299.7 | V | M35×P0.75 | 4K7μ |
| XM3508A | 35 | 0.08X | φ30 | 4.5 | ﹤0.01% | 508 | V | M37×P0.75 | 2K10μ/4K7μ |
| XM4010A | 40 | 0.1X | φ43.2 | 2.8 | ﹤0.5% | 400 | V | M37×P0.75 | 4K7μ |
| XM6016A | 60 | 0.167X | φ64 | 4 | ﹤0.2% | 404 | V | M37×P0.75 | 4K7μ/8K7μ |
| XM8003A | 80 | 0.3X | φ64 | 5.6 | ﹤0.01% | 320 | V | M37×P0.75 | 8K7μ/12K5μ |
| XM9001A | 90 | 0.1X | φ64 | 4 | ﹤0.01% | 992.4 | V | M58×P0.75 | 12K5μ/16K3.5μ |
| XM9005A | 95 | 0.05X | φ62 | 4 | ﹤0.005% | 1980 | V | M58×P0.75 | 12K5μ/16K3.5μ |
| XM0802A | 100 | 0.2X | φ66 | 4.5 | ﹤0.005% | 654.8 | V | M54×P0.75 | 8K7μ |
| XM4005B | 40mm | 0.05X | φ60 | 4 | ＜0.2% | 818.8 | M72×P0.75 | M72×P0.75 | 8k7u/12k5u |
