產(chǎn)品中心
| 型號(hào) | 倍率 | 最大像面尺寸 | 通光孔徑 | 物方數(shù)值孔徑 | 工作距離 | 視場角 | TV畸變 | 遠(yuǎn)心度 | 鏡頭總長 | 接口 | 物方分辨率 |
| XM0501A | 0.188X | 2/3" | 6.8-40 | 0.0138 | 167 | 46.8×35.2×58.5 | ﹤0.014% | 0.08º | 411.75 | C | 10.6μ |
| XM0502A | 0.22X | 2/3" | 6.8-40 | 0.015 | 167 | 40.06×30.04×50 | ﹤0.003% | 0.08º | 390.63 | C | 18μ |
| XM0503A | 0.367X | 4/3" | 5.9 | 0.0167 | 184.4 | 30.7×30.7×43.4 | ﹤0.1% | 0.08º | 429.2 | C | 18μ |
| XM1531A | 0.31X | 1.1＂ | 8-22 | 0.02 | 150 | 45.7*33.5*57.2 | ＜0.03% | 小于0.05% | 229.65 | C Mount | 16.12μ |
| XM1537A | 0.37X | 1.1＂ | 5.6-22 | 0.027 | 150 | 38*28.6*48 | ＜0.05% | ＜0.05° | 251 | C Mount | 15.1μ |
| XM2275A | 0.75X | 2/3° | 10 | 0.037 | 220 | 11.7*8.8*14.6 | ＜0.02% | ＜0.03° | 156 | C Mount | 9.1μ |
| XM6540A | 4X | 2/3 | 18° | 0.112 | 65 | 2.5*1.65*2.75 | ＜0.03% | ＜0.05° | 122 | C Mount | 3μ |
